Roots Wow Tile is our vision of the Terracota. Organic looking pieces of Art inspired in nature and the authenticity of the impact of time given by the character of aging graciously. Given its innovative dual finish of smooth touch and outstanding resistance coexisting, it can be used anywhere and particularly outdoors. Honest and meaningful designs, for a distinctive way of thinking.
ROOTS NO LIMITS! This collection has been created using a specially formulated matt enamel for use both indoors and outdoors. Thanks to an innovative non-slip surface R11 / Class 3 / DCOF > 0.42, Roots can be installed in wet areas. However, its soft-touch finish makes it suitable for interior use, allowing for aesthetically uniform spaces.
Roots L Sand- 66,6 % Roots M Sand- 33,3 %
CONTENTS ROOTS
Roots XXL Cotto – 66,6 % Roots XL Cotto – 33,3 %
SIZES, COLOURS AND FINISHES XXL 44X44 cm / 17.2”x17.2” XL 44×22 cm / 17.2”x8.6”
Sand Cotto Rust
WARNING! Due to the glaze specifications of colours: Honey,Teal,Turques,Indigo and Olive Gloss; It is strongly recommended to avoid using these products on kitchen countertops or any other surface where the tiles might be in contact with food.
L 22×22 cm / 8.6”x8.6” W20 W20 W20-W34* Sand,Cotto,Rust,Rust *White Gloss *Turques,Gloss,*Teal Gloss *Honey Gloss *Indigo Gloss *Olive Gloss M 11×22 cm / 4.3”x8.6” S 11×11 cm / 4.3”x4.3”
Roots XXL Sand – 66,6 % Roots XL Sand – 33,3 % Wall Tiles: Roots XL Sand Roots M Sand Roots L Sand Roots S Olive Gloss
Roots S Sand Roots S Honey Gloss
Roots S Cotto – 50% Roots S White Gloss – 50%
Roots XXL Sand Roots L Sand Wall Tiles: SB Teal Roots M Sand – 50 % Roots M Rust – 50 %
Roots L Rust – 80% Roots S Teal Gloss -20%
Roots L Rust -50% Roots M Rust – 50% Wall Tiles: Roots M Rust Roots XXL Rust 25% Roots XL Rust 38% Roots L Rust 37% Randomly Installed
Roots XXL Cotto – 66,6 % Roots XL Cotto – 33,3 % Skirting: Roots S Cotto Wall Tiles: Roots S White Gloss
Roots L Sand – 66,6 % Roots M Sand – 33,3 % Wall Tiles: Roots S White Gloss Roots L, M & S Sand Roots S Teal Gloss Roots S Honey Gloss Roots S White Gloss Randomly Installed
Roots M Sand Roots S Sand Roots S White Gloss
Roots L Sand Roots S Olive Gloss Roots S Sand
Roots L Sand Roots S Sand Roots S Turquese Roots L Cotto Roots S Cotto Roots S Turquese
Roots L Rust Roots M Rust Roots S Teal Gloss Bar Tiles: Zellige White Matt Roots S Rust Roots S Teal Gloss
Roots L Rust – 44,4% Roots M Rust – 44,4% Roots S Rust – 11,2%
Roots L Cotto Roots M Cotto Roots S Indigo Gloss
UNLIMITED COMPOSITIONS
Roots M – 100% Roots XXL – 66,7% Roots XL – 33,3% Roots L – 50% Roots M – 25% Roots S – 25% Roots L – 50% Roots M – 33,3% Roots S – 16,7% Roots M – 88,9% Roots S – 11,1% Roots L – 50% Roots M – 50% Roots XXL Rust – 95% Roots S Teal Gloss – 5%
LAYOUTS
Roots L Sand – 50% Roots S Sand – 25% Roots S Turques Gloss – 25%
Roots S Cotto – 50% Roots S White Gloss – 50%
Roots XXL – 66,7% Roots XL – 33,3% Roots L – 66,7% Roots M – 33,3% Roots M – 50% Roots S – 50% Roots S – 100% Roots L – 50% Roots M – 50% Roots M – 100%
TECHNICAL FEATURES Dry-pressed porcelain tiles whith water absorption B Ia ≤ 0,5% for interior and exterior floors and walls. Baldosas cerámicas prensadas en seco con absorción de agua B Ia ≤ 0,5% para suelos y paredes interiores y exteriores.
FEATURES / CARACTERÍSTICAS SPECIFICATION / ESPECIFICACIÓN NORMA /Dimensional Features 110 mm +/- 0,9 mm x 110 mm +/- 0,9 mm x 10 mm +/- 5% 110 mm +/- 0,9 mm x 220 mm +/- 0,6% x 10 mm +/- 5% 220 mm +/- 0,6% x 220 mm +/- 0,6% x 10 mm +/- 5% 220 mm +/- 0,6% x 440 mm +/- 0,6% x 10 mm +/- 5% 440 mm +/- 0,6% x 440 mm +/- 0,6% x 10 mm +/- 5%
Modulus of rupture Minimum 35 N/mm2 Individual Minimum 32 N/mm2
Chemical resistance GHA (Matt & White Gloss) GLB (Gloss) GHB (Gloss)
Stain resistance 5 UNE-EN ISO
Non-slip value R11 / CLASS 3 / DCOF >0,42 (EXCEPT GLOSS) DIN 51130:2014
Tone variation V5 – WARNING! Due to the glaze specifications of colours: Turques Gloss, Honey Gloss, Olive Gloss, Teal Gloss and Indigo Gloss, It is strongly recommended to avoid using these products on kitchen countertops or any other surface where the tiles might be in contactwith food.\
TECHNICAL DRAWINGS
XXL 440 mm 220 mm L 220 mm M 220 mm S 110 mm XL 440 mm
XXL 17.3” 8.6”/8.6” 4.3” 4.3” L 17.3” 8.6” M 8.6” S 4.3” XL 17.3”
XXL 10 mm 10 mm/10 mm 10 mm 10 mm L 440 mm 220 mm M 220 mm 110 mm 110 mm S 0.39” 0.39” XL 0.39” 0.39” 0.39”
